DMP

Processor	DM&P 32-bit x86 Vortex86DX3 Dual-core 1.0GHz SoC
Memory	1GB/2GB DDR3-1600MHz onboard
BIOS	AMI BIOS
Display	VGA Integrated Graphics Chip/D-Sub 15-pin (MAX. 1920 x 1080 pixels)
Disk support	SD Slot x1 IDE Primary Channel/Internal SD x1 (Optional)
Serial ports	DB9 COM ports x2 (MAX. RS-232 x2)
Ethernet	Realtek 8111F GbE x1
Audio	HD Audio Realtek ALC262VD Mic-in & Line-out
USB	USB V2.0 x3 (Front x2, Rear x1)
Auto Power On	Support
Power requirement	DC +5V/2A
Dimensions	95 x 95 x 20mm/95 x 95 x 35mm//VESA 75 x 75mm Support
Net Weight	277g/350g
Operation Temperature	0~60℃
Certifications	FCC, CE, UKCA, VCCI
OS Support	Windows 7, WES7, Windows XP, XPe, CE6.0, Compact 7 and Linux

Enlarge Fullscreen Mode to click the hyperlink for video

Dimensions unit: mm

Model Type	RAM	1 Gbps LAN	RS-232	Auto Power On	Operation Temperature
EBOX-3350DX3-GL	1GB DDR3	1x			0~60℃
EBOX-3350DX3-GLAP	1GB DDR3	1x		Support	0~60℃
EBOX-3350DX3-GLC2	1GB DDR3	1x	2x		0~60℃
EBOX-3350DX3-GLC2AP	1GB DDR3	1x	2x	Support	0~60℃
EBOX-3352DX3-GL	2GB DDR3	1x			0~60℃
EBOX-3352DX3-GLAP	2GB DDR3	1x		Support	0~60℃
EBOX-3352DX3-GLC2	2GB DDR3	1x	2x		0~60℃
EBOX-3352DX3-GLC2AP	2GB DDR3	1x	2x	Support	0~60℃

Model Type	DRAM	CPU	－	LAN	COM	Auto Power On	Wide Temperature
EB-335	0: 1GB	DX3: Vortex86DX3	－	GL: GbE LAN x1	C2: RS-232 x2	AP: Support	W: Support
	2: 2GB			None LAN x1	None No COM	None Not support	None Not support

The Vortex86 SoC Series are 32-bit x86-architecture microprocessors that are compatible with Windows, Linux and most popular 32-bit Real Time Operating Systems. The CPU clock ranges from a single core 300MHz to dual core 1GHz, and also integrates the L1 cache and L2 cache. They support Built-in ISA, PCI, PCIe, UART, IDE/SATA, I2C, SPI, CAN, GPIO, USB, etc., most of the legacy I/O interface into one single BGA package.

Website: http://www.vortex86.com/

Benchmark & Power Consumption index
